Hướng dẫn sử dụng và Thông số kỹ thuật
Front-End RF Filtering
–3 dB at 30.5 MHz from the center frequency of each band
Active RF Gain Control
31 dB
Adjusts RF sensitivity to provide more RF dynamic range
RF Sensitivity
at 20 dB SINAD
2.2 µV
Image Rejection
>90 dB
Adjacent Channel Rejection
>70 dB
Latency
0.37ms
Squelch Threshold
22 dB SINAD (±3 dB)
default setting
Intermodulation Attenuation
>70 dB
Blocking
>80 dB
Audio Output Power
1kHz @ 1% distortion, peak power, @16Ω
100 mW (per output)
4-band Parametric EQ
9.5 Ω
High Boost
| Low Shelf |
Selectable Gain: ±2 dB, ±4 dB, ±6 dB @ 100 Hz |
| Low Mid |
Selectable Gain: ±2 dB, ±4 dB, ±6 dB at 160 Hz, 250 Hz, 400 Hz, 500 Hz, 630 HzSelectable Q: 0.7, 1.4, 2.9, 5.0, 11.5 |
| High Mid |
Selectable Gain: ±2 dB, ±4 dB, ±6 dB at 1 kHz, 1.6 kHz, 2.5 kHz, 4 kHz, 6.3 kHzSelectable Q: 0.7, 1.4, 2.9, 5.0, 11.5 |
| High Shelf |
Selectable Gain: ±2 dB, ±4 dB, ±6 dB @ 10 kHz |
Volume Limiter
Selectable: OFF (0 dB) to -48 dB in 3 dB steps
Volume Lock
Selectable: 0 dB to -70 dB
Limits volume adjustment knob. Selected value analogous to volume knob increment.
Net Weight
154 g (Without Battery)
Dimensions
83 x 65 x 22 mmH x W x D
Battery Life
4–6 hours (continuous use) AA batteries
