MODEL |
Behringer Eurocom CL108T |
Frequency Range |
53 Hz to 20 kHz (-10 dB)
|
Frequency Response |
60 Hz to 15 kHz (±3 dB)
|
Dispersion |
Nominal
Horn Waveguide: 90 x 70º (H x V), rotatable
|
Directivity |
Factor (Q): 7.5
Index (DI): 8.8 dB
|
Sensitivity |
1 W at 3.2' (1 m) Passive: 91 dB (half space)
|
Crossover |
Modes: Passive
|
Crossover Frequency |
2 kHz
|
Power Handling |
150 W rms at 100 W rms 34.6 V (long term, IEC passive)
|
Nominal Impedance |
8 Ω
|
Low Frequency Driver |
8" (203.2 mm) at 150 W
|
High Frequency Driver |
1" (25.4 mm) at 20 W
|
SPL |
Maximum Continuous: 113 dB SPL (passive)
Maximum Peak: 119 dB SPL (passive)
|
Overload Protection |
Full range power limiting to protect drivers and crossovers
|
Transformer |
At 100 V: 25 W, 50 W, 100 W
|
Enclosure |
Trapezoidal 15° side angle, laminated birch plywood
|
Grille |
Steel
|
Rigging Points |
14 x M6 threaded points
4 x M6 threaded inserts for OmniMount 30 series
|
Termination |
5-position terminal strip connection
|
Dimensions |
19.3 x 10.2 x 11.3" (490.2 x 259.0 x 287.0 mm)
|
Weight |
23.6 lb (10.7 kg)
|
