Behringer Eurocom CL108
8" Ultra-Compact 150W 2-Way 8 Ohm Loudspeaker System (Black)
Compact in stature but big on output, the black 8” Ultra-Compact 150W 2-Way 8Ω Loudspeaker System from Behringer delivers an impressive sonic performance. This professional 2-way loudspeaker system is suitable for a wide variety of fixed installation applications.
Viewed34 times
Compact in stature but big on output, the black 8” Ultra-Compact 150W 2-Way 8Ω Loudspeaker System from Behringer delivers an impressive sonic performance. This professional 2-way loudspeaker system is suitable for a wide variety of fixed installation applications. Featuring clean lines and a fabric-finished wrap-around grille, the speaker system is fully at home in the most elegant settings, including theaters and auditoria, places of worship, themed entertainment, and sporting venues. Although designed for serving as mains in small rooms, the CL108 Loudspeaker System can also be used as fill and delay systems in larger rooms.
Built of quality laminated Baltic birch plywood, the CL108’s lightweight cabinet combines natural rigidity and acoustic inertness with the additional strength of internal steel bracing. Threaded mounting-point inserts in the internal brackets provide a rated load factor of at least 10 times the overall cabinet weight, making this system safe for flown installation, either single or in arrays. The system also achieves fully-professional performance and reliability with its custom-tailored components for frequency response, sensitivity, and power handling.
This system employs dual 8" (203.2mm) low frequency drivers providing full, rich lows matched to a 1" (25.4mm) high frequency driver via an internal passive crossover at 2 kHz to deliver clear, smooth sound across the entire audible spectrum. A rotatable waveguide allows optimal application of the 90 x 70° coverage pattern regardless of speaker orientation, which may be either vertical or horizontal.
Every aspect of the CL108 speaker system has been thought through to maximize value and convenience for both the installer and the end user. The result is an attractive, durable, installation-ready loudspeaker system that will deliver top-notch sound for years to come. In addition, the refined aesthetic design compliments your sophisticated interior spaces. This loudspeaker system is trapezoidal in shape with rotatable high-frequency sections for deployment in both vertical and horizontal orientations.
Built of quality laminated Baltic birch plywood, the CL108’s lightweight cabinet combines natural rigidity and acoustic inertness with the additional strength of internal steel bracing. Threaded mounting-point inserts in the internal brackets provide a rated load factor of at least 10 times the overall cabinet weight, making this system safe for flown installation, either single or in arrays. The system also achieves fully-professional performance and reliability with its custom-tailored components for frequency response, sensitivity, and power handling.
This system employs dual 8" (203.2mm) low frequency drivers providing full, rich lows matched to a 1" (25.4mm) high frequency driver via an internal passive crossover at 2 kHz to deliver clear, smooth sound across the entire audible spectrum. A rotatable waveguide allows optimal application of the 90 x 70° coverage pattern regardless of speaker orientation, which may be either vertical or horizontal.
Every aspect of the CL108 speaker system has been thought through to maximize value and convenience for both the installer and the end user. The result is an attractive, durable, installation-ready loudspeaker system that will deliver top-notch sound for years to come. In addition, the refined aesthetic design compliments your sophisticated interior spaces. This loudspeaker system is trapezoidal in shape with rotatable high-frequency sections for deployment in both vertical and horizontal orientations.
- Professional sound reinforcement loudspeaker system designed for a variety of fixed installation applications
- Impressive sound quality with wide frequency bandwidth & uniform dispersion
- 150W 8" (203.2mm) low-frequency transducer provides deep bass for small to medium sized rooms
- Constant directivity 90 x 70° (H x V) rotatable waveguide (constructed from polypropylene) with 1" (25.4mm) phenolic dome high-frequency transducer
- Passive crossover with overload circuitry ensures optimal driver protection
- Professional speaker connector (compatible with Neutrik Speakon connectors) and 4-position terminal strip with captive wire clamps and removable plastic cover, with IN terminals wired in parallel to OUT terminals and to the NL4 connectors
- Internally braced and acoustically inert 15° trapezoidal birch plywood enclosure designed for cluster applications
- Multiple threaded 14 M6 inserts for flexible installation including Omnimount products; includes matching yoke bracket
- Powder coated steel grille wrapped with acoustically transparent fabric and foam and matching black cabinet color
- Internally braced and acoustically inert 15° trapezoidal birch plywood enclosure ideal for cluster applications
- High-quality components and rugged construction ensure long life
- 1 NL4 connector, wired in parallel as a full-range input to the passive crossover
MODEL | Behringer Eurocom CL108T |
Frequency Range |
53 Hz to 20 kHz (-10 dB)
|
Frequency Response |
60 Hz to 15 kHz (±3 dB)
|
Dispersion |
Nominal
Horn Waveguide: 90 x 70º (H x V), rotatable |
Directivity |
Factor (Q): 7.5
Index (DI): 8.8 dB |
Sensitivity |
1 W at 3.2' (1 m) Passive: 91 dB (half space)
|
Crossover |
Modes: Passive
|
Crossover Frequency |
2 kHz
|
Power Handling |
150 W rms at 100 W rms 34.6 V (long term, IEC passive)
|
Nominal Impedance |
8 Ω
|
Low Frequency Driver |
8" (203.2 mm) at 150 W
|
High Frequency Driver |
1" (25.4 mm) at 20 W
|
SPL |
Maximum Continuous: 113 dB SPL (passive)
Maximum Peak: 119 dB SPL (passive) |
Overload Protection |
Full range power limiting to protect drivers and crossovers
|
Transformer |
At 100 V: 25 W, 50 W, 100 W
|
Enclosure |
Trapezoidal 15° side angle, laminated birch plywood
|
Grille |
Steel
|
Rigging Points |
14 x M6 threaded points
4 x M6 threaded inserts for OmniMount 30 series |
Termination |
5-position terminal strip connection
|
Dimensions |
19.3 x 10.2 x 11.3" (490.2 x 259.0 x 287.0 mm)
|
Weight |
23.6 lb (10.7 kg)
|
