Stunning fidelity from a stylish and affordable CD player.
By combining high-quality components and decades of Onkyo audio technical knowledge, the C-7030 CD player delivers a superb playback experience. The key lies in keeping the audio signal clean and free from interference, all the way to the output stage.
To achieve this, we employ a new high-precision clock to dramatically reduce timing errors, along with our original VLSC™ to reduce pulse noise.
Driving the system is a massive, custom-built transformer that provides a clean and stable power supply. Given how affordable the C-7030 is, build quality is exceptional. A 1.6 mm-thick flat chassis base helps reduce unwanted vibrations, while the sleek aluminum front panel provides an elegant finish.
FEATURES
- Plays Audio CD, CD-R, CD-RW, MP3 CD, and WMA CD*
- VLSC (Vector Linear Shaping Circuitry) for Pulse Noise Reduction
- Custom-Designed Massive EI Transformers
- Precision Clock (±10 ppm)
- Wolfson® 192 kHz/24-Bit D/A Converter
- Differential Headphone Amplifier Circuitry
- 25-Track Memory Playback
- 2 Digital Audio Outputs (Optical and Coaxial)
- Analog Audio Output
- 1.6 mm-Thick Anti-Vibration Full-Flat Chassis
- Solid Aluminum Front Panel
- 3-Mode Display Dimmer (Normal/Dim/Dimmer)
- Auto Standby Function
- RI (Remote Interactive) Remote Control
Frequency Response 4 Hz-20 kHz/+1 dB, -3 dB (DSP bypass)
THD (Total Harmonic Distortion) 0.0029%
Signal-to-Noise Ratio 107 dB
Audio Dynamic Range 100 dB
Audio Output/Impedance
Optical
Coaxial
Analog
-22.5 dBm
0.5 Vp-p/75 Ω
2V (rms)/600 Ω
Power Supply AC 220-240 V~, 50/60 Hz
Power Consumption 12W
Dimensions (W x H x D) 435 x 101 x 306 mm
Weight 5.3 kg
Carton Dimensions (W x H x D) 564 x 200 x 413 mm
Carton Weight 7.2 kg
Supplied Accessories Instruction manual, RCA audio cable,
Remote controller, AAA (R03) batteries x 2
