ONKYO TX-8130

HIGHLIGHTS
110 W per Channel
Internet Radio and Music Streaming including Spotify Connect
Phono Input
Hi-Current Amp Design
384 kHz/32-bit Hi-Grade DAC
4 Quick-Access BGM Presets
AMPLIFIER AND CONNECTION FEATURES
Non-Phase-Shift Amp Design for Realistic Sound Imaging
Discrete Amplifier Design with Massive EI Transformer
Two Custom-Made 8,200 μF Hi-Current Capacitors
AKM AK4452 384 kHz/32-bit Hi-Grade DAC
Plays Music from Mass-Storage-Class USB Memory Devices
Supports Onkyo Remote App for Control of Receiver via iPod touch/iPhone and Android™ Devices*1
Plays Compressed, Lossless, and Hi-Res Audio via Local Network (MP3, WMA, WMA Lossless, FLAC, WAV, Ogg Vorbis, AAC, Apple Lossless, DSD 5.6 MHz, and LPCM)
Internet Radio and Music Streaming Subscription Services Included (TuneIn Radio, Spotify, and Deezer)*2
Certified with Windows® 8 and DLNA Version 1.5
Direct Mode
2 Digital Audio Inputs (1 Optical and 1 Coaxial)
6 Analog Audio Inputs (Excluding Phono Input) and 1 Output
MM Phono Input
Subwoofer Pre Out
Speaker A/B Drive
Headphone Jack
*1 Compatible models: iPod touch 3rd generation or later, iPhone 3GS or later running iOS 4.2 or later; Android 2.1 or later.
*2 Availability of services depends on region.
TUNER FEATURES
AM/FM Tuner with 40 Station Presets
Preset Station Naming (Up to 10 Characters)
OTHER FEATURES
Anti-Vibration Oval Chassis
Banana Plug-Compatible Speaker Posts
Front USB Port Supports WAV 96 kHz, DSD 2.8 MHz, and MP3 Playback
Auto Power On via Optical When Signal is Detected
Independent Bass, Treble, and Balance Controls
Network Standby Capability
3-Mode Display Dimmer (Normal/Dim/Dimmer)
Sleep Timer
Battery-free Memory Back-up
Compatible with RI (Remote Interactive) Dock for iPod/iPhone
Full-Function RI Remote Control
GENERAL SPECIFICATIONS
Power Output: 110 W/Ch (6 Ohms, 1 kHz, 1%, 1 Channel Driven, IEC); 115 W/Ch (6 Ohms, 1 kHz, 2 Channels Driven, JEITA)
Frequency Response: 10 Hz–100 kHz/+1 dB, -3 dB (Direct Mode)
Dimensions (W x H x D): 435 x 149 x 328 mm
Weight: 7.9 kg
