Magnificent Sound Meets Ultimate Versatility
With 135 W/Ch of pure high-current analog power courtesy of a discrete low-impedance amplification system, your speakers are driven with depth and clarity no matter what audio source you select. And there are so many options: TV sound via digital inputs, music streaming from Spotify over Wi-Fi®, iTunes via AirPlay, MP3s from USB drives, audio from mobile apps via Bluetooth technology, and both FM and DAB+ radio. There’s also a phono equalizer for your turntable and other players can be connected using the four digital and six analog inputs. BGM Preset stores four of your best FM, DAB+, and internet radio stations, so entertainment is only a button push away. Don’t settle for second best: with almost 70 years’ experience building premium Hi-Fi gear, nothing else performs like an Onkyo.
Hi-Current Non-Phase-Shift Amplification
High current enhances control of the speakers for extremely accurate and dynamic sound. It’s the cornerstone of our WRAT system, which also prevents phase shift by pushing the roll-off point higher than the listening-level frequency. This creates an uncommonly well-focused and realistic audio image.
Hi-Grade 384 kHz/32-bit DAC
An Asahi Kasei AK4452 digital-to-analog converter unlocks the full potential of any audio format thanks to unique low-distortion sound-enhancing filtering technologies.
Quick-Access Presets
Get instant access to four of your favorite FM, DAB+, and internet radio stations at the touch of a button.
Rediscover the Magic of Vinyl
Hi-current amplification brings out the best in your vinyl records—just connect your turntable via the phono input. Long-time collector or just starting out, the TX-8150 will delight with authentic Hi-Fi sound.
Bluetooth Audio, Wi-Fi®, and AirPlay with Spotify
Stream virtually any audio to your system with zero hassle. Available internet radio and music subscription services include Spotify and TuneIn, while a DAB+ tuner adds a wealth of quality radio entertainment options.
Ready for Hi-Res Audio
The TX-8150 is engineered for universal Hi-Res compatibility and ease of use. Use the remote app to select your 192/24 FLAC or 5.6 MHz DSD files on PC or NAS and bask in the clarity and detail of high-resolution music.
With 135 W/Ch of pure high-current analog power courtesy of a discrete low-impedance amplification system, your speakers are driven with depth and clarity no matter what audio source you select. And there are so many options: TV sound via digital inputs, music streaming from Spotify over Wi-Fi®, iTunes via AirPlay, MP3s from USB drives, audio from mobile apps via Bluetooth technology, and both FM and DAB+ radio. There’s also a phono equalizer for your turntable and other players can be connected using the four digital and six analog inputs. BGM Preset stores four of your best FM, DAB+, and internet radio stations, so entertainment is only a button push away. Don’t settle for second best: with almost 70 years’ experience building premium Hi-Fi gear, nothing else performs like an Onkyo.
Hi-Current Non-Phase-Shift Amplification
High current enhances control of the speakers for extremely accurate and dynamic sound. It’s the cornerstone of our WRAT system, which also prevents phase shift by pushing the roll-off point higher than the listening-level frequency. This creates an uncommonly well-focused and realistic audio image.
Hi-Grade 384 kHz/32-bit DAC
An Asahi Kasei AK4452 digital-to-analog converter unlocks the full potential of any audio format thanks to unique low-distortion sound-enhancing filtering technologies.
Quick-Access Presets
Get instant access to four of your favorite FM, DAB+, and internet radio stations at the touch of a button.
Rediscover the Magic of Vinyl
Hi-current amplification brings out the best in your vinyl records—just connect your turntable via the phono input. Long-time collector or just starting out, the TX-8150 will delight with authentic Hi-Fi sound.
Bluetooth Audio, Wi-Fi®, and AirPlay with Spotify
Stream virtually any audio to your system with zero hassle. Available internet radio and music subscription services include Spotify and TuneIn, while a DAB+ tuner adds a wealth of quality radio entertainment options.
Ready for Hi-Res Audio
The TX-8150 is engineered for universal Hi-Res compatibility and ease of use. Use the remote app to select your 192/24 FLAC or 5.6 MHz DSD files on PC or NAS and bask in the clarity and detail of high-resolution music.
HIGHLIGHTS
135 W per Channel
Built-in Wi-Fi® for Wireless Audio
Bluetooth Audio Support for Wireless Audio Playback
Spotify Connect and AirPlay
Phono Input
Hi-Current Amp Design
384 kHz/32-bit Hi-Grade DAC
4 Quick-Access BGM Presets
AMPLIFIER AND CONNECTION FEATURES
Non-Phase-Shift Amp Design for Realistic Sound Imaging
Discrete Amplifier Design with Massive EI Transformer
Two Custom-Made 8,200 µF Hi-Current Capacitors
AKM AK4452 384 kHz/32-bit Hi-Grade DAC
Plays Music from Mass-Storage-Class USB Memory Devices
Supports Onkyo Remote App for Control of Receiver via iPod touch/iPhone and Android™ Devices*1
Plays Compressed, Lossless, and Hi-Res Audio via Local Network (MP3, WMA, WMA Lossless, FLAC, WAV, Ogg Vorbis, AAC, Apple Lossless, DSD 5.6 MHz, and LPCM)
Internet Radio and Music Streaming Subscription Services Included (TuneIn Radio, Spotify, and Deezer)*2
Certified with Windows® 8 and DLNA Version 1.5
Pure Audio Mode
Direct Mode
4 Digital Audio Inputs (2 Optical and 2 Coaxial)
6 Analog Audio Inputs (Excluding Phono Input) and 1 Output
MM Phono Input
Subwoofer Pre Out
Speaker A/B Drive
IR Input and Output
Gold-Plated Headphone Jack
*1 Compatible models: iPod touch 3rd generation or later, iPhone 3GS or later running iOS 4.2 or later; Android 2.1 or later.
*2 Availability of services depends on region.
TUNER FEATURES
FM/DAB/DAB+ Tuner with 40 Station Presets
Preset Station Naming (Up to 10 Characters)
OTHER FEATURES
Anti-Vibration Oval Chassis
Gold-Plated Audio Terminals
Banana Plug-Compatible Speaker Posts
Front USB Port for WAV 96 kHz, DSD 2.8 MHz, and MP3 Playback
Auto Power On via Optical When Signal is Detected
Independent Bass, Treble, and Balance Controls
Network Standby Capability
3-Mode Display Dimmer (Normal/Dim/Dimmer)
Sleep Timer
Battery-free Memory Back-up
Compatible with RI (Remote Interactive) Dock for iPod/iPhone
Full-Function RI Remote Control
GENERAL SPECIFICATIONS
Power Output: 135 W/Ch (6 Ohms, 1 kHz, 1%, 1 Channel Driven, IEC); 140 W/Ch (6 Ohms, 1 kHz, 2 Channels Driven, JEITA)
Frequency Response: 10 Hz–100 kHz/+1 dB, -3 dB (Direct Mode)
Dimensions (W x H x D): 435 x 149 x 328 mm
Weight: 8.6 kg
