SHURE MX395

SHURE MX395

Microflex Low Profile Boundary Microphones
Boundary microphone delivers exceptional sound pickup and a low-profile design in a variety of colors and pickup patterns to suit any meeting room. It features wide dynamic range and smooth frequency response, remote LED control, and 3 color options.
7,668,000đ
Brand:
Product Code:MX395
FEATURES:
  •     Only 1.25 inch (3.8 cm) in diameter
  •     Cardioid, omni and bidirectional polar patterns
  •     Wide dynamic range and smooth frequency response
  •     Available in black, white and aluminum
  •     Bi-color status indicator available with -LED models
  •     Logic input for remote LED control
All measurements taken with microphone mounted on a wooden surface (76 x 76 cm)

Cartridge Type: Electret Condenser

  • Frequency Response: 5017000 Hz
  • Polar Pattern

MX395/O

Omnidirectional

MX395/C

Cardioid

MX395/BI

Bidirectional

  • Output Impedance: 170 Ω
  • Output Configuration: Active Balanced
  • Sensitivity @ 1 kHz, open circuit voltage

Cardioid

−35 dBV/Pa (18 mV)

Omnidirectional

−28 dBV/Pa (42 mV)

Bidirectional

−37 dBV/Pa (14 mV)

1 Pa=94 dB SPL

  • Maximum SPL (1 kHz at 1% THD, 1 kΩ load)

Cardioid

121 dB

Omnidirectional

114 dB

Bidirectional

123 dB

  • Equivalent Output Noise (A-weighted)

Cardioid

28 dB SPL

Omnidirectional

21 dB SPL

Bidirectional

29 dB SPL

  • Signal-to-Noise Ratio (Ref. 94 dB SPL at 1 kHz)

Cardioid

66 dB

Omnidirectional

73 dB

Bidirectional

65 dB

  • Dynamic Range (1 kΩ load, @ 1 kHz)

Cardioid

93 dB

Omnidirectional

93 dB

Bidirectional

94 dB

  • Common Mode Rejection (10 to 100,000 kHz): 45 dB, minimum
  • Preamplifier Output Clipping Level at 1% THD: −8 dBV (0.4 V)
  • Logic Connections

LED IN

Active low (≤1.0V), TTL compatible. Absolute maximum voltage: -0.7V to 50V.

  • Net Weight: 136 g (0.30 lbs)
  • Environmental Conditions

Operating Temperature

–1857°C (0135°F)

Storage Temperature

–2974°C (–20165°F)

Relative Humidity

095%

  • Power Requirements:

MX395

1152  V DC, 2.0 mA

MX395-LED

4852  V DC, 8.0 mA
