Configurable PoE-powered mute button accessory designed for Shure networked audio products, including Microflex® Advance™ Array Microphones as well as the IntelliMix® P300 and IntelliMix Room DSPs, and ANIUSB-MATRIX. One or many of the low-profile touch sensitive mute buttons can be configured to mute one or multiple microphones, depending on user needs or room configurations.
Select a Combination
Designer System Configuration software for easy setup and configuration
SystemOn™ Asset Management for remote management & troubleshooting
PoE powered
Compatible with third party control systems via programmable control strings
LED status ring with configurable colors and brightness
Configurable as toggle, push to talk and push to mute functionality
IPX1 rated
Easy table installation in 1” (25mm) or 7/8” (22mm) holes
Available with or without microphone icon
ELECTRICAL
Connector Type: RJ45, 8-pin power cable
Cable Requirements: Cat 5e or higher (shielded cable recommended)
Power Requirements: Power over Ethernet (PoE), Class 1
Power Consumption: 2 W, maximum
Control Software: Shure Designer
Ingress Protection Rating: IEC 60529 IPX1 Water Protected
MECHANICAL
Operating Temperature Range: −6.7°C (20°F) to 40°C (104°F)
Storage Temperature Range: −29°C (-20°F) to 74°C (165°F)
DIMENSIONS (H x W x D)
Base: 3.74 x 3.74 x 1.06 in. (94.96 x 94.96 x 27.04 mm)
Mute Button: 1.54 x 1.54 x 0.2 in. (39.02 x 39.02 x 5.02 mm)
Mute Button Tube: 0.87 x 0.87 x 3.03 in. (22 x 22 x 76.98 mm)
Grommet: 1.97 x 1.97 x 0.31 in. (49.97 x 49.97 x 8 mm)
Spacer: 1.93 x 1.93 x 0.05 in. (49 x 49 x 1.2 mm)
