SHURE WH20TQG

Name: SHURE WH20TQG - Dynamic Headset Microphone
Brand: Shure
Price: 3348000 VND
Availability: InStock

Dynamic Headset Microphone

The Shure WH20 is a rugged, lightweight, dynamic headset microphone that provides high-quality voice pickup. It fits securely for active microphone users, such as aerobics instructors and musicians, with low visibility for stage appearances.

3,348,000đ

Brand: Shure

Product Code:WH20TQG

Wish List
Compare

Overview
SPECS

The cardioid (unidirectional) pickup pattern provides greater gain-before-feedback and isolation from ambient noise and other unwanted sound sources. A carefully shaped frequency response includes a voice-frequency presence peak and a low-frequency roll-off to compensate for the proximity effect inherent in cardioid mics during close-talk operation.

Lightweight wireframe and elastic headband adjust for a secure, comfortable fit
Extra-strong, small-diameter attached microphone cable resists breakage
Collapsible microphone boom for easy storage and transportation
Smooth, natural frequency response comparable to high-quality dynamic hand-held vocal microphones
High input clipping level eliminates overload distortion
Reliable at temperature and humidity extremes
Supplied foam windscreen and clothing clip

Show More Show Less

Type: Dynamic, Close-Talking
Frequency Response: 50 to 15,000 Hz
Polar Pattern: Cardioid (unidirectional)
Impedance: Rated at 150 ohms (200 ohms actual)
Output Level (close talked* at 1,000 Hz): Open Circuit Voltage: -67.0 db/Pa (0.45 m)
Hum Sensitivity: 38.4 dB equivalent SPL in a 1 millioersted field
Polarity:
- WH20QTR as a wired microphone: Positive sound pressure on diaphragm produces positive voltage on tip with respect to sleeve (ground) of microphone output phone plug connector.
- WH20QTR, WH20TQG used with Shure Wireless Systems:
1/4-inch Phone Jack Receiver Outputs: Positive sound pressure on diaphragm produces positive voltage on tip of receiver output connector.
3-pin XLR Receiver Outputs: Positive sound pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3 of low-impedance output connector, and on tip of Aux output connector.
- WH20XLR as a wired microphone: Positive sound pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3 of microphone output XLR connector.
Environmental Conditions:
- Operating Temperatures: -18° to 60° C (0° to 140°F)
- Storage Temperatures: -29° to 74°C (-20° to 165°F)
- Humidity: 0 to 95%
Cable: Attached 1.22 m (4 ft), small-diameter, shielded, PVC-jacketed, two-conductor.
Construction: Black thermoplastic housing; stainless steel grille; black TEFLON®-coated stainless steel wireframe; flexible plastic-clad monel gooseneck; rubber/nylon elastic headband
Net Weight (including connector):
- WH20: 63 g (2.2 oz)
- WH20TQG: 63 g (2.2 oz)
- WH20XLR: 98 g (3.5 oz)

SHURE WH20TQG
