Behringer Eurocom SN2408

Name: Behringer Eurocom SN2408 - Mixer và Ampli đôi 80W
Brand: Behringer
Availability: InStock

Mixer 80W và Ampli đôi

The Eurocom SN2408 80-Watt Mixer and Dual Amplifier from Behringer is designed for continuous operation in distributed music, paging, and AV applications in bars, recreation facilities, conference rooms, hotels, and other venues. It is powered by two independent Class-D mono amplifiers with DC and thermal overload protection. The first amplifier has a high impedance output and can be set to either 70 or 100 volts. The second amplifier has a standard low-impedance output.

Hãng sản xuất: Behringer

Mã sản phẩm:SN2408

Yêu thích
So sánh

Tổng quan
Thông số kỹ thuật

Xem nhiều hơn Xem ít hơn

MODEL	Behringer Eurocom SN2408
Inputs	Microphone Inputs: 3x Combo XLR/TRS jacks 3x 4-pin Euroblock connectors Auxiliary Inputs: 2x Stereo RCA (summed) Telephone/Page Input: 1x 3-pin Euroblock connector Amp Inputs: 2x RCA
Outputs	Zone 1 Speaker Output: 1x 4-pin Euroblock connector (LO-Z and HI-Z) Zone 2 Line Level Output: 1x 3-pin Euroblock connector Preamp Outputs: 2x RCA
Input Impedance	Microphone Combo XLR/TRS Inputs: -50 dBv @ 600 Ω (balanced) Euroblock Inputs: 0 dBv @ 10 k Ω (balanced) Auxiliary Inputs: 0 dB @ 10 kΩ (unbalanced) Telephone/Page Input: -10 dBv @ 600 Ω (balanced)
Output Impedance	4 dBV @ 600 Ω balanced
Phantom Power	24 VDC
Amplifier	Channels: LO-Z: 1x 4 Ω (minimum) HI-Z: 1x 70/100 V (switchable) Power Output LO-Z: 80 W RMS @ 8 Ω, 1 % THD, 1 kHz sine wave, minimum 4 Ω Power Output HI-Z: 80 W RMS @ 70 V (minimum 62.5 Ω) 160 W RMS @ 100 V (minimum 62.5 Ω, 1 % THD @ 1 kHz sine wave)
Controls	3x Mic/Line gain (inputs 1 to 5) 1x Lo Tone knob ± 15 dB @ 100 Hz 1x Hi Tone knob ± 15 dB @ 10 kHz 1x Master Volume knob 1x Telephone/Page Level knob 1x Zone 2 Send Level knob 1x Mute Depth knob 1x Power On/Off switch 1x Voltage 115/230 VAC switch 1x HI-Z Mode 70/100 V switch 3x Phantom/Mic/Line 3 position DIP switch 1x Mute Assign 8-position DIP switch 1x Output Assign 8-position switch
Indicators	1x Dual-function indicator ring (yellow - power on; red - clip)
Circuit	Type: 2x Transformerless Class D Dual Output: LO-Z & HI-Z
Protection	Amplifier: Thermal and DC protection, automatic limiters
Frequency Response	50 Hz to 218 kHz (± 1 dB @ 1 W, 70 / 100 V)
Dynamic Range	Mic: 65 dB Auxiliary: 80 dB Telephone/Page: 78 dB
Total Harmonic Distortion/Noise	0.05 % @ 1 W (1 kHz dBr into 8 Ω load)
Signal to Noise Ratio	90 dB @ 1% THD+N
Power Supply	Mains Voltage: 100 to 120 VAC (switchable), 220 to 240 VAC, 50/60 Hz Fuse: T 6.3 A H 250 V Power Efficiency: 70% Power Consumption: 80 W @ 1/8 of maximum rated output Mains Connector: Standard IEC receptacle
Dimensions	3.3 x 12.0 x 14.2" (8.3 x 30.5 x 36.0 cm)
Weight	9.2 lb (4.2 kg)
