dBTechnologies DVA M2M+M2S

Name: dBTechnologies DVA M2M+M2S - 2-Way Active Line Array System
Brand: dBTechnologies
Availability: InStock

2-Way Active Line Array System

Offering the same user-friendliness and sound quality of its DVA predecessors, this 2-Way Active Line Array System sets the new benchmark for high-end sound performance thanks to the innovative Master+Slave design which aacks high SPL in incredibly small dimensions and weight. A super versatile system for both portable and permanent installation solutions.

Brand: dBTechnologies

Product Code:DVA M2M+M2S

Wish List
Compare

dbtechnologies dva m2m+m2s

Overview
SPECS

Each unit of DVA MINI system is comprised of two line array modules, each with two 6.5” neodymium woofers and two 1” high-frequency compression drivers. The M2M module is the master module that contains the 400-watt Digipro G3 amplifier that power both the M2M and M2S slave module. The system achieves 126 dB Max SPL: per unit. Constructed in solid Polipropilene reinforced with an internal anti-vibration structure, DVA MINI features a new fast-lock mechanic design: users simply place one module below the other and slide it towards one side until it locks in place. Moreover, every DVA MINI module has a back mechanic with incremental steps allowing different line array positioning angles.

Show More Show Less

Technical Data
Speaker Type M2M: 2-Way Active Master Line Array Module
Speaker Type M2S: 2-Way Slave Line Array Module
Acoustical data
Frequency Response [-6dB]: 78 - 19.000 Hz
Frequency Response [-10dB]: 68 - 20.000 Hz
Max SPL: 126 dB per unit
HF: 2x1"
Type HF: Neodymium
Voice Coil HF: 1"
LF: 2x6.5"
Type LF: Neodymium
Voice Coil LF: 1.5"
Directivity: 90x15°
Amplifier
Amp Technology: Digipro® G3
Amp Class: Class D
RMS Power HF Amp: 200 W (100 W + 100 W)
RMS Power LF Amp: 200 W (100 W + 100 W)
Cooling: Convection
Processor
Controller: DSP 56 bit
AD/DA Converter: 24 bit/48 kHz
System Presets: 9 presets (8x HF and Low-Mid corrections and 1x for service use)
Limiter: Multiband, RMS/Peak, Thermal
CrossOver Frequency LF-HF: 1800 Hz
Slope LF-HF: 24 dB/Octave
Input
Signal Input: 1x XLR fem, Bal.
Signal Output: 1x XLR male, Bal.
Power Supply: 400W SMPS with PSU Auto-range (110V~ and 220V~)
Power Socket: 1x PowerCon In 1x PowerCon Out
Signal Input M2S: 1 Custom connector
Mechanics
Housing: Polypropylen PP
Handles: 2x back side
Fittings: Integrated hardware with fast lock mechanics
Splay Angles: 0°- 1,5°- 3°- 4,5° - 6°- 8°- 10°- 12,5°- 15°
Width: 460 mm (18.1 in)
Height: 190 mm (7.5 in)
Depth: 345 mm (13.6 in)
Weight M2M: 7.6 kg (16.8 lbs)
Weight M2S: 7.1 kg (15.7 lbs)
