Single Ethernet port carries Dante audio, power (PoE – class 0)
LEDs indicate device status and audio signal
Control strings for third-party preset controllers including Crestron® and AMX®
4 Band C/S PEQ on every channel
Provides channel summing to combine Dante™ signals from the network and send them over a single analog output
Browser-based software control for all device parameters, per output channel:
Mute control
Digital gain
Polarity control
1/3 Rack unit wide
Chassis ground screw (BLOCK version only) provides common chassis ground for multiple inputs
Available in block connector and standard XLR variations
Input: (1) RJ45
Outputs: (4) XLR connector
Configuration: Impedance Balanced
Polarity: Non-inverting, any input to any output
Power Requirements: Power over Ethernet (PoE), Class 0
Power Consumption: 10W, maximum
Weight: 663 g (1.5 lbs)
Dimensions (H x W x D): 4 x 14 x 12.8 cm (1.6 x 5.5 x 5.0 in.)
Control Application: HTML5 Browser-based
Operating Temperature Range: −6.7°C (20°F) to 40°C (104°F)
Storage Temperature Range: −29°C (-20°F) to 74°C (165°F)
Audio
Frequency Response: 20 to 20,000 Hz
Input (Dante Digital Audio): Channel Count: 4; Sampling Rate: 48 kHz, Bit Depth: 24
Latency (Does not include Dante latency): 0.71 ms
Dynamic Range (Dante-to-Analog): 20 Hz to 20 kHz, A-weighted, typical; 117 dB
Total Harmonic Distortion (@ 1 kHz, -20 dBFS Output, 0 dB analog gain): <0.05%
Output Clipping Level:
- Line: +20 dBV
- Aux: +0 dBV
- Mic: -26 dBV
Analog Output Level (Selectable)
- Line: 0 dB
- Aux: - 20 dB
- Mic: -46 dB
Output Impedance: 150 Ω
Built-in Digital Signal Processing:
- Per Channel Equalizer (4-band Parametric), Mute, Invert Polarity, Gain (140 dB range)
- System: Audio Summing
