SHURE ANIUSB-MATRIX
USB Audio Network Interface with Matrix Mixing
Audio network interface connects up to 4 Dante channels and 1 analog output to a room's audio and video conferencing system via USB connection. Internal matrix mixer offers flexible routing, allowing users to route any input to any output.
Viewed172 times
The ANIUSB-MATRIX USB Audio Network Interface complements the existing ANI4IN, ANI4OUT, and ANI22 products. It offers the ideal performance, connectivity, and affordability for audio/video conferencing installations in small and medium-size meeting rooms when a premium microphone solution is desired, and acoustic echo cancellation of an A/V conferencing codec will be used.
The ANIUSB-MATRIX connects 4 Microflex Advance or Microflex Wireless microphone channels via Dante (4 in / 2 out), provides analog connectivity (1 block in / 1 block out) to a room audio/video conferencing system or a PC-based A/V conferencing application via USB (1 in/out).
An internal matrix mixer offers flexible routing, allowing users to route any input to any output. A 4-band parametric EQ filter is also available on the analog and USB outputs.
Feature
Connects 4 Dante audio inputs and 1 analog input to a AV conferencing system or a PC-based videoconferencing application
Flexible signal routing and connectivity: analog audio (1 block in / 1 block out) to room AV conferencing system; USB (1 in/out) to connect to laptop or room PC
Power-over-Ethernet (PoE) eliminates the need for an outboard power supply
Compact form factor is easy to mount without equipment rack
The ANIUSB-MATRIX connects 4 Microflex Advance or Microflex Wireless microphone channels via Dante (4 in / 2 out), provides analog connectivity (1 block in / 1 block out) to a room audio/video conferencing system or a PC-based A/V conferencing application via USB (1 in/out).
An internal matrix mixer offers flexible routing, allowing users to route any input to any output. A 4-band parametric EQ filter is also available on the analog and USB outputs.
Feature
Connects 4 Dante audio inputs and 1 analog input to a AV conferencing system or a PC-based videoconferencing application
Flexible signal routing and connectivity: analog audio (1 block in / 1 block out) to room AV conferencing system; USB (1 in/out) to connect to laptop or room PC
Power-over-Ethernet (PoE) eliminates the need for an outboard power supply
Compact form factor is easy to mount without equipment rack
Analog Connections
- Input: (1) 3-pin block connector (Active Balanced)
- Output: (1) 3-pin block connector (Impedance Balanced)
USB Connections: (1) USB 2.0, Type B
Network Connections (Dante Digital Audio): (1) RJ45; 4 input channels, 2 output channels
Polarity: Non-inverting, any input to any output
Power Requirements: Power over Ethernet (PoE), Class 0. (PoE Plus compatible).
Power Consumption: 6.5W, maximum
Weight: 668 g (1.5 lbs)
Dimensions (H x W x D): 4 x 14 x 12.8 cm (1.6 x 5.5 x 5.0 in.)
Control application: HTML5 Browser-based
Operating Temperature Range: −6.7°C (20°F) to 40°C (104°F)
Storage Temperature Range: −29°C (-20°F) to 74°C (165°F)
Thermal Power Dissipation:
- Maximum: 6.8W (23.0BTU/hr)
- Typical: 6.0W (20.8BTU/hr)
Audio
Frequency Response (+1, -1.5 dB): 20 to 20,000 Hz
Dante Digital Audio:
- Sampling Rate: 48 kHz
- Bit Depth: 24
USB Audio
- Sampling Rate: 44.1, 48 kHz
- Bit Depth: 16, 24
Latency (Does not include Dante latency)
- Analog to Analog: 0.98 ms
- Analog to Dante: 0.39 ms
- Dante to Analog: 0.72 ms
- Dante to Dante: 0.14 ms
Dynamic Range (20 Hz to 20 kHz, A-weighted, typical)
- Analog-to-Dante: 113 dB
- Dante-to-Analog: 117 dB
Equivalent Input Noise (20 Hz to 20 kHz, A-weighted, input terminated with 150Ω)
- Line: -86 dBV
- Aux: -98 dBV
Total Harmonic Distortion (@ 1 kHz, 0 dBV Input, 0 dB analog gain): <0.05%
Common Mode Rejection Ratio (150Ω balanced source @ 1 kHz): >70 dB
Impedance: 10.6 kΩ
Input Clipping Level
- Line: +27 dBV
- Aux: +15 dBV
Output Clipping Level
- Line: +20 dBV
- Aux: +0 dBV
- Mic: -26 dBV
Built-in Digital Signal Processing
- Per Channel: Equalizer (4-band Parametric, Analog and USB output channels only), Mute, Limiter, Gain (140 dB range)
- System: Matrix mixer
Networking
Cable Requirements: Cat 5e or higher (shielded cable recommended)
- Input: (1) 3-pin block connector (Active Balanced)
- Output: (1) 3-pin block connector (Impedance Balanced)
USB Connections: (1) USB 2.0, Type B
Network Connections (Dante Digital Audio): (1) RJ45; 4 input channels, 2 output channels
Polarity: Non-inverting, any input to any output
Power Requirements: Power over Ethernet (PoE), Class 0. (PoE Plus compatible).
Power Consumption: 6.5W, maximum
Weight: 668 g (1.5 lbs)
Dimensions (H x W x D): 4 x 14 x 12.8 cm (1.6 x 5.5 x 5.0 in.)
Control application: HTML5 Browser-based
Operating Temperature Range: −6.7°C (20°F) to 40°C (104°F)
Storage Temperature Range: −29°C (-20°F) to 74°C (165°F)
Thermal Power Dissipation:
- Maximum: 6.8W (23.0BTU/hr)
- Typical: 6.0W (20.8BTU/hr)
Audio
Frequency Response (+1, -1.5 dB): 20 to 20,000 Hz
Dante Digital Audio:
- Sampling Rate: 48 kHz
- Bit Depth: 24
USB Audio
- Sampling Rate: 44.1, 48 kHz
- Bit Depth: 16, 24
Latency (Does not include Dante latency)
- Analog to Analog: 0.98 ms
- Analog to Dante: 0.39 ms
- Dante to Analog: 0.72 ms
- Dante to Dante: 0.14 ms
Dynamic Range (20 Hz to 20 kHz, A-weighted, typical)
- Analog-to-Dante: 113 dB
- Dante-to-Analog: 117 dB
Equivalent Input Noise (20 Hz to 20 kHz, A-weighted, input terminated with 150Ω)
- Line: -86 dBV
- Aux: -98 dBV
Total Harmonic Distortion (@ 1 kHz, 0 dBV Input, 0 dB analog gain): <0.05%
Common Mode Rejection Ratio (150Ω balanced source @ 1 kHz): >70 dB
Impedance: 10.6 kΩ
Input Clipping Level
- Line: +27 dBV
- Aux: +15 dBV
Output Clipping Level
- Line: +20 dBV
- Aux: +0 dBV
- Mic: -26 dBV
Built-in Digital Signal Processing
- Per Channel: Equalizer (4-band Parametric, Analog and USB output channels only), Mute, Limiter, Gain (140 dB range)
- System: Matrix mixer
Networking
Cable Requirements: Cat 5e or higher (shielded cable recommended)
