The BLX2/SM58 Handheld Wireless Microphone Transmitter works with BLX Wireless Systems.
Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.
Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.
FEATURES
- Integrated microphone capsule design
- Lightweight, rugged construction
- -10 dB gain attenuation
- Color ID caps (available separately)
- Applications: Vocals, Karaoke
- Sound source: Accordion, Choir, Cowbell, Electric Guitar / Amp, Harmonica, Speech, Ukulele, Vocals
- Environment: Club, Fitness Center, Live Performance, Place of worship, Rehearsal Space
System
BLX2
- Working Range: 91 m (300 ft) Line of Sight
- Audio Frequency Response: 50 to 15,000 Hz
- Total Harmonic Distortion Ref. ±33 kHz deviation with 1 kHz tone 0.5%, typical
- Dynamic Range: 100 dB, A-weighted, typical
- Operating Temperature: -18°C (0°F) to 57°C (135°F)
- Polarity: Positive pressure on microphone diaphragm (or positive voltage applied to tip of WA302 phone plug) produces positive voltage on pin 2 (with respect to pin 3 of low-impedance output) and the tip of the high impedance 1/4-inch output.
BLX2
- Audio Input Level:
| 0dB | -20 dBV maximum |
| -10dB | -10 dBV maximum |
- Gain Adjustment Range: 10 dB
- RF Transmitter Output: 10 mW, typical
- Dimensions: 8.82 in. X 2.09 in. (224 mm X 53 mm) L x Dia.
- Weight: 7.7 oz. (218 g) without batteries
- Housing: Molded ABS
- Power Requirements: 2 LR6 AA batteries, 1.5 V, alkaline
- Battery Life: up to 14 hours (alkaline)
