SHURE MXW2/SM58

SHURE MXW2/SM58

Handheld Transmitter with SM58 Capsule
Coupled with the SM58 cartridge, the MXW2 is a handheld transmitter compatible with Microflex Wireless Systems. With lightweight but durable construction and integrated diversity antennas, the MXW2 delivers vivid lifelike sound, intelligent wireless performance, encrypted transmission, and advanced rechargeability for presentation and conferencing applications.
Brand:
Product Code:MXW2/SM58
Featuring lightweight yet durable construction, MXW2/SM58 delivers vivid lifelike sound, intelligent wireless performance, encrypted transmission, and advanced rechargeability for conferencing and presentation applications.

All Microflex Wireless transmitters deliver vivid lifelike sound, intelligent wireless performance, encrypted transmission, and advanced rechargeability for conferencing and presentation applications.

FEATURES
  • Dual transmit antennas: Maximizes transmission strength depending on hand placement
  • Bi-directional wireless: Enables real-time remote control of all wireless microphone settings
  • Programmable mute button: Allows customization of local or remote muting behavior per application, with options including push-to-talk, push-to-mute, and external control
  • Standby mode: Enabled remotely during breaks or periods of inactivity to significantly extend battery life when not in use
  • Wide working range: Reliable wireless coverage extends up to 160 feet (50 meters)
  • Range warning alert: Emits beeping sound when range limit is exceeded
  • Easy transmitter linking: Assign the microphone to an access point channel by simply docking it into a networked charging station and pressing “Link”
  • Encrypted wireless: AES 256-bit encryption for secure transmission
  • Advanced Li-ion batteries: Smart lithium-ion internal batteries provide up to 9 hours of continuous use, charge fully in 2 hours, and enable remote monitoring over the network of remaining runtime and charge status in hours and minutes
  • USB charging: Connects to any standard USB power source for “always on” usage. Charge time using SBC-USB adapter: <3.5 hours while mic is in use
  • Anti-roll design: Features a flat resting point to prevent the microphone from accidentally rolling off a flat surface

Application: Conference, A/V Conferencing, Discussion
SoundSources: Accordion, Choir, Cowbell, Electric Guitar / Amp, Harmonica, Speech, Ukulele, Vocals
Environment: Board Room, Conference Room, Hotel &amp; Convention, Huddle Room, Meeting Room, Auditorium, Class Room, Lecture Hall, Council, Courtroom, Parliament

System

  • RF Carrier Frequency Range: 1880 - 1900 MHz/li>
  • Audio Frequency Response:65 Hz - 16 kHz
  • Power Consumption: 2.5 W
  • Maximum Output Power: 3.0 W RMS
  • Preamplifier Output Clipping Level: <1% THD
  • Signal-to-Noise Ratio: <90  dB A-weighted
  • Cable Requirements: Cat 5e or higher
  • Dimensions: 61 x 150 x 168 mm
  • Weight: 650 g
  • Operating Temperature Range: 5℃ (41℉) - 40℃ (104℉)



Transmitters

  • Gain Adjustment Range: −25 to +15 dB (in 1 dB steps)
  • Maximum Input Level (Mic gain @ −16 dB): −9 dBV
  • Headphone Output: 3.5 mm (1/8″), dual mono (will drive stereo phones)
  • Maximum Headphone Output Power (1kHz @ 1% distortion, peak power, @16Ω): 17.5 mW
  • Antenna Type: Internal, Spatial Diversity, Linear Polarization
  • Antenna Gain
Average
-1.1 dBi
Peak
0.5 dBi
  • Charge Connector: USB 3.0 Type A
  • Housing: Molded Plastic
  • Recommended Storage Temperature Range: 0°C (32°F) to 25°C (77°F)
  • Battery Life
SB902, Standard Density Mode
SB902, High Density Mode SB905, Standard Density Mode SB905, High Density Mode
Up to 15 hours
Up to 16 hours Up to 23 hours Up to 29 hours


MXW2 Handheld Transmitter

  • Configuration: Unbalanced
  • Input Impedance (@ 1 kHz): >20 kΩ
  • Dimensions: 226 mm × 51 mm (8.9 in. × 2.0 in.) L × Dia. including SM58 microphone capsule
  • Weight: 323 g (11.4 oz.) with batteries, including SM58 microphone capsule
