SHURE Nexadyne™ 6

Transducer Type
Dynamic (moving coil) with secondary vibration-cancelling dynamic transducer

Polar Pattern
Supercardioid

Frequency Response
50 Hz–16 kHz

Output Impedance
at 1 kHz

335 Ω

Sensitivity
open circuit voltage, @ 1 kHz, typical

–60.5 dBV/Pa (0.94 mV/Pa) [1]

Polarity
Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3.

Weight
246 g (0.54 lbs.)

Connector
Three-pin professional audio (XLR), male

Housing
Die-cast zinc with black paint

[1] 1 Pa=94 dB SPL

Nexadyne Instrument Microphones Spec Sheet(en)


Tổng quan

Nexadyne Instrument Microphones Sell Sheet(en)

• 1 micro cho trống kick Shure NXN6
• 1 kẹp micro cho trống A6D
• 1 Túi zip đựng micro
