SHURE P10R+

P10R+

Tri-Band RF Filtering

–3 dB at 30.5 MHz from the center frequency of each band

Active RF Gain Control

31 dB

Adjusts RF sensitivity to provide more RF dynamic range

Active RF Sensitivity

at 20 dB SINAD

2.2  µV

Image Rejection

>90 dB

Adjacent Channel Rejection

>70 dB

Latency

0.37ms

Squelch Threshold

22 dB SINAD (±3 dB)

default setting

Intermodulation Attenuation

>70 dB

Blocking

>80 dB

Audio Output Power

1 kHz at Less than 1%distortion, Maximum Headphone Output Power, at 16 Ω

100 mW (per output)

Minimum Load Impedance

4 Ω

Output Impedance

<1 Ω

4-band Parametric EQ

Volume Limiter

Selectable: OFF (0 dB) to -48  dB in 3 dB steps

Volume Lock

Selectable: 0  dB to -70  dB

Limits volume adjustment knob. Selected value analogous to volume knob increment.

Net Weight

158 g (Without Battery)

Dimensions

99 x 66 x 23 mm (3.9 in. x 2.6 in. x 0.9 in.) H x W x D

Battery Life

4–6 hours (continuous use) AA batteries
