SHURE SBRC
The Shure Battery Rack Charger (SBRC) provides a seamless, touring-ready battery charging and storage solution.
Interchangeable charging modules support a variety of Shure Lithium-ion batteries, accommodating up to 8 batteries in a single rack space.
An easy-to-read front panel displays critical parameters including charge levels, time-to-full, and battery health indicators such as temperature and cycle count. Shure Wireless Workbench® software provides remote monitoring of battery status when SBRC is connected to a network.
Control and Insight
- Comprehensive status display with straightforward three-button interface control
- Easily visible charge status by percentage and time-to-full readings in hours and minutes
- Battery health tracking metrics indicate percentage of original capacity and cycle count
- Remote monitoring of battery status available through Shure Wireless Workbench software
Versatility
- Interchangeable charging modules allow users to mix and match up to 8 Shure bodypack and handheld transmitter batteries
- Charges batteries to 50 percent capacity within an hour and full capacity within 3 hours
- Storage mode prepares batteries for optimal long-term storage
- Charges Shure SB900B, AXT910 and AXT920 rechargeable batteries
Battery Type
Up to 8 rechargeable Li-Ion batteries
Charge Time
50%=1 hour; 100%=3 hours
Charging Module Type
Up to 4 charging modulesin any combination
Operating Temperature Range
-18°C (0°F) to 63°C (145°F)
Battery Charging Temperature Range
0°C (32°F) to 60°C (140°F)
Storage Temperature Range
-29°C (-20°F) to 74°C (165°F)
Dimensions
44 mm x 483 mm x 366 mm (1.7 in. x 19.0 in. x 14.4 in.), H x W x D
Weight
4.4 kg (9.8 lbs), without batteries or charging modules
Housing
Steel; Extruded aluminum
Power Requirements
Input | 100 to 240 V AC, 50-60 Hz |
Output | 4.5 V DC maximum, 60 W maximum |
Current Drain
1.8 A
RMS (referenced at 90 V AC)
Networking
Network Interface
Ethernet 10/100 Mbps
Network Addressing Capability
DHCP or Manual IP address
