SHURE SCM800E

SHURE SCM800E

Eight Channel Microphone Mixer
8-channel microphone mixer offers compatibility with any low-impedance, balanced microphone, including wireless microphone systems. Includes adjustable EQ, phantom power LED, manual mixing, and peak-responding output limiter.
29,160,000đ
Brand:
Product Code:SCM800E
The Shure Model SCM800 is a full-featured, eight-channel microphone mixer for sound reinforcement, general audio recording, and audio-visual systems. Any low-impedance, balanced dynamic or condenser microphone, including a wireless microphone system, can be used with the SCM800 mixer.

Each SCM800 accepts up to eight microphone- or line–level inputs and one aux-level input (two input jacks feed the same channel). Up to four SCM800 mixers can be linked to provide up to 32 input channels. Each input channel has a two-band equalizer, switchable microphone- or line-level operation, switchable 48 V phantom power, and a 1/4-inch send/receive insert jack.
  • Compatible with Shure SCM410, SCM810 and FP410 automatic microphone mixers
  • Adjustable EQ per channel: low-frequency rolloff and high-frequency shelving
  • 48 V phantom power selectable for each input
  • Active balanced microphone- and line-level inputs and line level output
  • Highly RF-resistant chassis and circuitry
  • LED indication of channel clipping
  • Linking capability for systems up to 32 microphones
  • Two Aux-level input jacks that feed one channel
  • Insert jack on each channel
  • Manual mixing of input channels
  • Internal Modification permits 230 V operation (SCM800) or 120 V operation (SCM800E)
  • Front-panel headphones output with level control
  • Peak-responding output limiter with selectable thresholds and LED indicator
  • Frequency Response (Ref .1 kHz, channel controls centered): 50 Hz to 20 kHz +-2 dB; -3 dB corner at 25 Hz
  • Total Harmonic Distortion: <0.1%at +18 dBV output level, 50 Hz to 20 kHz (through 20 Hz-20 kHz filter); Input 1 and Master at 5, all other controls full counterclockwise)
  • Hum and Noise
  • - Equivalent Input Noise: -125 dBV(150 Ω source; through 400 Hz-20 kHz filter)
  • - Equivalent Input Hum and Noise: -123 dBV(150 Ω source; through 20 Hz-20 kHz filter)
  • - Output Hum and Noise: through 20 Hz-20 kHz filter; channel controls full counterclockwise
  • - Master full counterclockwise: -90 dBV
  • - Master full clockwise: -62 dBV
  • Common Mode Rejection Ratio: >70 dB at 1 kHz
  • Polarity: Mic/Line, Send inputs to all outputs are non-inverting; Aux input to all outputs is inverting
  • Overload and Shorting Protection: Shorting outputs, even for prolonged periods, causes no damage. Microphone inputs are not damaged by signals up to 3 V; Lines and Monitor inputs by signals up to 20 V
  • Equalization
  • - Low-frequency: 6 dB/octavecut, adjustable corner from 25 to 320 Hz
  • - High-Frequency: ±6dB/octaveat 5 kHz, ±  dBat 10 kHz, shelvingat 5
  • Limiter
  • - Type:  Peak
  • - Threshold  Switchable: off, +4, +8, +16 ( dBm at output)
  • - Attack: 2 ms
  • - Recovery: 300 ms
  • - Indicator: Lights red when limiting occurs
  • Input LEDs: Light at 6 dBbelow clipping
  • Phantom Power: 46 V DC open-circuit through6.8 k Ω series resistance per DIN 45 596
  • Operating Voltage: 230 V AC rated nominal, 50/60  Hz, 100  mA
  • Temperature Range
  • - Operating Temperature:  0° to 60° C (32° to140° F)
  • - Storage Temperature:  -30° to 70° C (-22° to158° F)
  • Dimensions: 44.5 mm H x 483 mm W x 317 mm D (1¾ x 19 x 12½ in.)
  • Net Weight: 4.3 kg (9  lb ., 9  oz.)
