TwinPlex™ TH53 Subminiature Headset Microphone
The TwinPlex™ TH53 offers the natural sound of the TwinPlex element combined with the ease of an ultra-light and fully adjustable headset frame. With an innovative clutch system, the TH53 headset allows for quick adjustment in boom arm length and pitch—all with a simple turn of a knob. Plus, switchable sides and a durable 1.6 mm cable with redundant ground round out this professional headset that overachieves in reliability, audio quality, and comfort.
Brand:
Product Code:TH53T/O-MTQG
  • Comfortable, lightweight, and fully adjustable headset for use in theater, broadcast, and speech applications
  • Innovative clutch system allows for fast boom arm length and pitch adjustment
  • Twice the surface area of other subminiature microphones for pristine, natural response and robust low-frequency response due to the patent pending dual-diaphragm design
  • Improved off-axis consistency yields accurate reproduction regardless of vocal source position or movement
  • Best-in-class low self-noise and dynamic range for cleaner audio production
  • Interchangeable sweat- and moisture-resistant frequency caps prevents sweat-outs due to an invisible syperhydrophobic nanoscopic coating
  • Paintable 1.6 mm cable that is immune to memory effect and kinks
  • Dual redundant ground in cable serves as secondary shield for longevity
  • Sound signature: Natural
  • Sensitivity: Low
  • Colors: Tan, Cocoa, Black
  • Connectors: LEMO, MTQG/TA4F, MicroDot, NC (bare wire)
  • Accessories: Ships with accessories and storage case

In dialogue or monologue. Song or speech. A single word can affect the whole story. Shure TwinPlex stands up to the toughest conditions to make every word a clear statement of quality. Natural audio at high or low frequency, the innovative dual-diaphragm captures the complete weight of your voice. And the capsule design maximizes effective surface area in an easy-to-conceal package. So sound suits performer, not the other way around.

No more “sweat-outs.” The superhydrophobic coating keeps perspiration from upstaging the sound. And the medical-grade cable technology flexes to fit the costume design and the demanding schedule. So your headset rises to the challenge, night after night.

The TwinPlex™ TH53 offers the natural sound quality of the new TwinPlex element combined with the ease of a light and fully adjustable headset frame. With an innovative clutch system, the TH53 headset allows for quick adjustment in boom arm length and pitch—all with a simple turn of a knob. Plus, switchable sides and a durable 1.6 mm cable with redundant ground round out this professional headset that outperforms the competition in reliability, audio quality, and comfort.

Applications: Theater, Speech, Vocals,  Presentation
Sound source: Speech, Vocals
Environment: Broadcast Studio, Conference Room, Hotel Convention, Corporate Presentation, Auditorium, Lecture Hall, Live Performance, Place of worship, Theater Stage, TV/film set
  • Microphone Capsule: Dual-Diaphragm, Prepolarized Condenser
  • Polar Pattern: Omnidirectional
  • Frequency Response: 20 Hz to 20 kHz
  • Sensitivity: -45.0 dBV (5.62 mV) at 1 kHz[2]
  • Self-Noise, A-Weighted, Equivalent Acoustical: 24.5 dB SPL-A
  • Signal-To-Noise Ratio[3]: 69.5 dB
  • Output Clipping Level: 3.0 dBV,1 kHz at 1% THD, typical
  • Maximum SPL[4]: 142.0 dB SPL,1 kHz at 1% THD, typical
  • Dynamic Range: 117.5 dB, typical
  • Microphone Current Draw: 120 to 240 µA, typical
  • Bias Voltage (Recommended Operating Voltage): 5 V DC
  • Housing: Molded ABS
  • Polarity

MTQG

Positive pressure on diaphragm produces positive voltage on pin 3 with respect to pin 1

LEMO, NC, MDOT

Positive pressure on diaphragm produces negative voltage on pin 3 with respect to pin 1.

  • Cable Diameter: 1.6 mm
  • Cable Length

MTQG, LEMO, MDOT

66 in. (1.67 m)

NC

96 in. (2.43 m)

  • Net Weight
Boom arm with cable 12.0 g (0.42 oz.)
Headset frame 6.0 g (0.21 oz.)

[1]All specifications measured with a 48 Vdc phantom power supply. The microphone operates at lower voltages, but with slightly decreased headroom and sensitivity.

[2] 1 Pa=94 dB SPL

[3]S/N ratio is the difference between 94 dB SPL and equivalent SPL of self noise, A-weighted

[4]THD of microphone preamplifier when applied input signal level is equivalent to cartridge output at specified SPL
