SHURE WL183

SHURE WL183

Omnidirectional TQG Lavalier Microphone
Omnidirectional TQG lavalier microphone offers an interchangeable cartridge and consists of a tie clip and foam windscreen. Features include wide dynamic range and frequency response for accurate sound reproduction and increased immunity to noise.
4,428,000đ
Brand:
Product Code:WL183-X
  • Wide dynamic range and frequency response for accurate sound reproduction across the audio spectrum
  • Interchangeable cartridges that provide an optimal choice for each application
  • Rotatable tie-clip that pivots in 90 degree increments for placement flexibility
  • Supplied snap-fit foam windscreen that controls breath noise and stays on securely
  • Balanced, transformerless output for increased immunity to noise over long cable runs
  • Supplied dual tie clip holds two microphones for dual miking applications

diễn giả nói chuyện bằng micro cài áo shure wl183


What is the WL183 best suited to?

The WL183 omnidirectional miniature lavalier condenser microphone is designed for use in speech applications such as broadcast presenting, speeches, lectures and for use in houses of worship.

Phân biệt búp hướng các micro cài áo shure wl183 wl184 wl185 và shure mx183 mx184 mx185


What is an interchangeable cartridge?

All the microflex series of microphones use interchangeable cartridges (sold seperately) which means you can swap between cardioid, supercardioid and omnidirectional condenser cartridges simply by screwing them on to the top of the lavalier mic.


Micro cài áo Shure WL183


Want to use it wired?

The WL183 is designed for wireless use with a bodypack transmitter. If you wish to use it wired, choose the MX183 which is the same microphone but including an in-line preamplifier and a 1.2m cable with TA4F connector.


Micro lavalier Shure WL183


Find An Answer

How to Choose the Best Lavalier Microphone
Shure Lavalier / Headset compatibility with Wireless Systems



  • Type: Condenser (electret bias)
  • Frequency Response: 50 to 17,000  Hz
  • Output Impedance: 1800  Ω
  • Sensitivity [1]

WL183

-40.0  dBV/Pa

WL184

-44.5  dBV/Pa

WL185

-45.5  dBV/Pa

  • Maximum SPL

WL183

125.0  dB SPL

WL184

129.5  dB SPL

WL185

130.5  dB SPL

  • Self Noise (A-Weighted):

WL183

22.5  dB SPL

WL184

27.0  dB SPL

WL185

28.0  dB SPL

  • Dynamic Range: 102.5  dB
  • Polarity: Positive pressure on diaphragm produces positive voltage on pin 3 with respect to pin 1
  • Power Requirements: Regulated nominal +5 Vdc (1.5 Vdc to 10 Vdc) provided at microphone connector pin 2 relative to pin 1 of a Shure wireless microphone transmitter
