Shure Lavalier / Headset compatibility with Wireless Systems

Question

Which Shure lavalier and headset microphones are compatible with which Shure wireless systems? The following chart provides compatibility information between Shure lavalier and headset mics and Shure wireless systems for TQG (TA4F) native devices. This table does not apply to systems which use LEMO3 or other connectors.


Device	Twinplex	Duraplex	WL93	WL183, WL184 WL185	WH30 SM35	MX150	MX153	WBH53, WBH54	CVL, PG185	PGA31, SM31FH
ADX1 (TQG)
AD1 (TQG)
ULXD1 (TQG)
QLXD1
SLXD1
PGXD1
GLXD1
MXW1							(1)
BLX1
SLX1
RPM400TQG
RK100PK (2)

Notes:

MXW1 transmitters may not correctly detect an MX153 microphone. Set the transmitter to External mode in the Microflex Wireless software when using an MX153 element.
RK100PK adds 10 dB of gain to the microphone compared to RPM400TQG.
