SHURE ADX1

Name: SHURE ADX1 - Bodypack Transmitter
Brand: Shure
Availability: InStock

Bodypack Transmitter

ADX1, like all ADX transmitters, sets the stage for exceptional performance, with wide tuning up to 184 MHz, interference protection, advanced rechargeability, streamlined design, and ShowLink remote control for real-time parameter adjustments right from the booth. Includes two SB910 rechargeable batteries.

Brand: Shure

Product Code:ADX1

Wish List
Compare

The ADX1 is a wireless bodypack transmitter compatible with Axient Digital Wireless Systems.

Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.

FEATURES

Removable antenna and fully concealed buttons and switch
Two connector options: TA4 and LEMO3
Advanced control menu with powerful features
Durable, moisture-resistant, lightweight metal case
Up to 10 hours of runtime with SB910 rechargeable battery
Diversity ShowLink enabled for remote transmitter control and automatic interference avoidance
External contacts for docked charging
Two transmission modes: Standard for optimal coverage and new High Density for maximum system channel count and robust coverage
Encryption-enabled, secure transmission

Application: TV/Film & ENG, Theater
Environments: Auditorium, Lecture Hall, Live Performance, Place of worship, Rehearsal Space, Stadium, Stage & Event, Theater Stage

Show More Show Less

Gain Offset Range: –12 to 21 dB (in 1 dB steps)
Battery Type: SB910 Rechargeable Lithium-Ion
Battery Run Time @10 mW: up to 10 hours
Dimensions (H × W × D): 3.6 × 2.7 × 0.8 in (91 × 68 × 19 mm)
Weight: 5.0 oz (142 g)
Housing: Aluminum

AUDIO INPUT

Connector: 4-Pin male mini connector (TA4M)/ LEMO3 Connector
Configuration: Unbalanced
Impedance:

- TA4M: 1 mΩ
- LEMO3: 8.2 MΩ

Maximum Input Level 1 kHz at 1% THD:
- Pad Off: 8.5 dBV (7.5 Vpp)
- Pad On: 20.5 dBV (30 Vpp)
Preamplifier Equivalent | Input Noise (EIN) | System Gain Setting ≥20: –120 dBV

RF OUTPUT

Connector: SMA
Antenna Type: UHF 1/4 Wave
Impedance: 50 Ω
Occupied Bandwidth: <200 kHz
Modulation Type: Shure Axient Digital Propietary
Power: 2 mW, 10 mW, 20 mW, 40 mW
Specific Absorption Rate (SAR): <0.20 W/kg

SHOWLINK®

Network Type: IEEE 802.15.4
Antenna Type: ZigBee Dual Conformal
Frequency Range: 2.40 to 2.4835 GHz (24 Channels)
RF Output Power (Varies By Region): 10 dBm (ERP)
