SHURE SLXD14/DL4

SHURE SLXD14/DL4

Wireless System with SLXD1 Bodypack Transmitter and DL4 Lavalier Microphone
Featuring the DL4 IP57-rated waterproof subminiature lavalier microphone (black) and the SLXD1 transmitter to provides transparent digital audio and rock-solid RF stability for lecture halls and live performances.
Brand:
Product Code:SLXD14AZ/DL4B
The SLXD14/DL4 Digital Wireless System delivers transparent, 24-bit digital audio and rock-solid RF performance for a wide range of applications, from day-long presentations to nighttime performances.

micro lavalier shure dl4

Operate up to 32 compatible systems per 44 MHz band, with easy setup and optional rechargeability accessories for wireless excellence, wherever required.  Ships with SLXD4 single-channel receiver, SLXD1 bodypack transmitter and DL4 IP57-rated waterproof subminiature omnidirectional lavalier microphone (black) with lavalier, antenna and rackmount accessories, and 2 AA batteries.
lavalier microphone shure dl4

SYSTEM

RF

  • RF Carrier Frequency Range: 470–937.5 MHz, varies by region (See Frequency Range and Output Power table)
  • Working Range: 100 m ( 328 ft)
  • RF Tuning Step Size: 25 kHz, varies by region
  • Image Rejection: >70 dB, typical
  • RF Sensitivity: −97 dBm at 10-5 BER

AUDIO

  • Latency: 3.2 ms
  • High-Pass / Low Cut Filter: 150 Hz @ -12 db/oct
  • Audio Frequency Response: 20 Hz– 20 kHz (+1, -2 dB)
  • Audio Dynamic Range: 118 dB at 1% THD, A-weighted, typical
  • Total Harmonic Distortion: <0.02%
  • System Audio Polarity: Positive pressure on microphone diaphragm produces positive voltage on pin 2 (with respect to pin 3 of XLR output) and the tip of the 6.35 mm (with respect to the ring of the 6.35 mm output) output.
  • Mic Offset Range: 0 to 21 dB (in 3 dB steps)

TEMPERATURE RANGE

  • Operating Temperature Range: -18°C (0°F) to 50°C (122°F)
  • Storage Temperature Range: -29°C (-20°F) to 74°C (165°F)


SLXD1

  • Battery Type: Rechargeable Li-Ion or 1.5 V AA batteries
  • Dimensions (H × W × D): 3.86 × 2.68 × 1.0 in (98 × 68 × 25.5 mm)
  • Weight: 3.1 oz (89 g)
  • Housing: PC/ABS

AUDIO INPUT
  • Connector: 4-Pin male mini connector (TA4M)
  • Configuration: Unbalanced
  • Impedance: 1 MΩ
  • Maximum Input Level: 8.2 dBV
  • Preamplifier Equivalent Input Noise (EIN): –118 dBV

RF OUTPUT
  • Antenna Type: 1/4 Wave
  • Occupied Bandwidth: <200 kHz
  • Modulation Type: Shure Propietary Digital
  • Power: 1 mW/10 mW


SLXD4 / SLXD4D

  • Dimensions
SLXD4
42 x 197 x 152 mm (1.65 x 7.76 x 5.98 in.), H x W x D
SLXD4D
42 x 393 x 152 mm (1.65 x 15.47 x 5.98 in.), H x W x D
  • Weight
SLXD4
816 g, without antennas
SLXD4D
1451 g, without antennas
  • Housing: Galvanized Steel
  • Power Requirements: 15 V DC @ 600 mA, supplied by external power supply (tip positive)


RF INPUT

  • Spurious Rejection: >75 dB, typical
  • Connector Type: BNC
  • Impedance: 50 Ω
  • Phantom Power Protection:
1/4" (6.35 mm)
Yes
XLR
Yes

AUDIO OUTPUT

  • Gain Adjustment Range: -18 to +42 dB (in 1 dB steps)
  • Configuration
1/4" (6.35 mm)
Balanced (Tip = audio +, Ring = audio -, Sleeve = ground )
XLR
Balanced (1=ground, 2=audio +, 3=audio −)
  • Impedance
1/4" (6.35 mm)
1.3 kΩ (670 ΩUnbalanced)
XLR (line)
400 Ω (200 ΩUnbalanced)
XLR (mic)
150 Ω
  • Full Scale Output
1/4" (6.35 mm)
+15 dBV differentially (+9 dBV single)
XLR
LINE setting= +15  dBV, MIC setting= -15  dBV
  • Mic/Line Switch: 30 dB pad

NETWORKING

  • Network Interface: Single Port Ethernet 10/100 Mbps
  • Network Addressing Capability: DHCP or Manual IP address
  • Maximum Cable Length: 100 m (328 ft)
